- 1 1/2 hp 1800 RPM, 4.4/2.2 amps 230/460 Volts 60hz. 3-Phase
- NEMA 145TC frame, C-face, Keyed Shaft 7/8" Diameter x 2 1/4"
- Service Factor: 1.15, Overload protection = None
- No Base, Reversible, Ball Bearings, Class F Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a single phase electric motor with a C-face mount. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. ODP = Open Drip Proof. 145TTDR16360
