sale
Marathon
K2104 Marathon 1/2 hp 1200 RPM 3-Phase 56 Frame TEFC (rigid base) 230/460V Marathon Motor
(No reviews)
Write a Review
Write a Review
Marathon
K2104 Marathon 1/2 hp 1200 RPM 3-Phase 56 Frame TEFC (rigid base) 230/460V Marathon Motor
$868.94
$763.37
SKU
MK2104
UPC
7.23E+11
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
230/460V
Horsepower
1/2 HP
RPM
1200
Phase
Three Phase
Frame
56
Enclosure
TEFC
Hertz
60 Hz
Amperage
2.7/1.4 Amps
Bearings
Ball Bearings
Service Factor
1.0
Insulation Class
Class B
Mounting
Rigid Base
- 1/2 hp 1800 RPM, 2.7/1.4 amps 230/460 Volts 60 Hz. 3-Phase
- NEMA 56 frame, Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.0, Overload protection = Auto
- Rigid Base, Reversible, Ball Bearings, Class B Insulation
- 1 Year Manufacture Warranty
Explosion-Proof three phase electric motor. Shaft has keyway. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled
Marathon # K49HN6385
Replaces Leeson A6T11XB22F, 111938.00
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM |
| Voltage | 230/460V |
| Horsepower | 1/2 HP |
| RPM | 1200 |
| Phase | Three Phase |
| Frame | 56 |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 2.7/1.4 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.0 |
| Insulation Class | Class B |
| Mounting | Rigid Base |
