112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty
112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty

Leeson

112429.00 Leeson | 1/2 hp 1800 RPM 56C Frame TENV 208-230/460V Wash Down Duty

(No reviews) Write a Review
$607.20
$514.40
SKU 112429
UPC 6.92E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TENV
Hertz 60 Hz
Amperage 2.0/1.0 Amps
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1/2 hp 1800 RPM, 2.0/1.0 amps 208-230/460 Volts 60hz. Three Phase Motor
  • NEMA 56C Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Leeson Washguard Motor -Rigid Base
  • Service Factor: 1.15 - overload protection = None - Class F Insulation
  • TEFC= Totally Enclosed Fan Cooled
  • 1 Year Manufacture Warranty

Leeson's original moisture-shedding "duck" motor. Durable Rust Oleum White epoxy paint. Stainless steel shaft, conduit box cover, nameplate and fan guard. Special gaskets, slingers and seals. Four endshield drains. Moisture resistant interior components. IRIS insulation system.

C6T17WK1J, 112429.00
Replaces Marathon N632, 056T17W99005

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TENV
Hertz 60 Hz
Amperage 2.0/1.0 Amps
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
