D12P2AH Nidec | 1/2 hp 1800 RPM 56H Frame 208-230/460V Open Drip Nidec Electric Motor

D12P2AH Nidec | 1/2 hp 1800 RPM 56H Frame 208-230/460V Open Drip Nidec Electric Motor

This general-purpose, three-phase electric motor is designed for continuous duty applications requiring reliable performance and premium efficiency. It serves as a direct replacement for similar 1/2 hp motors in industrial and HVAC equipment.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 208-230/460 V
• Amperage: 1.9/0.98 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56H Frame
• Shaft Dimensions: Keyed Shaft, 5/8" Diameter x 1 7/8" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base mount for secure installation and is rated for continuous operation at a 40°C ambient temperature. It includes Class B insulation and a service factor of 1.25 but does not have built-in overload protection. Wiring diagrams are provided on the motor nameplate for ease of connection.

Warranty

1 Year Manufacturer Warranty
