4HZ67 Dayton 1/3 HP Direct Drive Blower Motor 1650 RPM 115V

4HZ67 Dayton 1/3 HP Direct Drive Blower Motor 1650 RPM 115V

The 4HZ67 Dayton blower motor is a 1/3 HP, 1-speed PSC motor designed for direct drive applications. It serves as a reliable replacement for Dayton ventilator models 4HZ23, 4HZ41, and 4HZ43, suitable for continuous duty in HVAC and blower systems.

Key Specifications

• Horsepower: 1/3 HP
• RPM: 1650
• Voltage: 115 V, 60 Hz
• Amperage: 4.0 A
• Enclosure: Open Air Over
• Frame / Diameter: 5 5/8" Diameter
• Shaft Dimensions: 1/2" diameter x 3" length
• Rotation: CCWSE (Counterclockwise Shaft End)
• Bearings: Ball Bearings

Product Features & Fitment

This motor features automatic overload protection and a service factor of 1.0, ensuring durability and safe operation under continuous duty. It includes four mounting studs located opposite the shaft end for secure installation. The motor is CSA Certified and UL Recognized, with Class B insulation for thermal protection.

Warranty

1 Year Manufacturer Warranty
