1419 Nidec | 1.5 hp 1725 RPM 208-230V Carrier Replacement Motor

1419 Nidec | 1.5 hp 1725 RPM 208-230V Carrier Replacement Motor

This 1.5 horsepower, 1725 RPM single-speed motor is designed as a direct replacement for Carrier, Bryant, and Payne motors, specifically the HD56FL652 model. It is ideal for HVAC applications requiring reliable, continuous-duty performance with 3-phase power.

Key Specifications

• Horsepower: 1.5 hp
• RPM: 1725
• Voltage: 208-230V
• Amperage: 5.0-4.8 amps
• Enclosure: Open Drip Proof
• Frame / Diameter: NEMA 56 Frame
• Shaft Dimensions: 5/8" diameter x 2" length
• Rotation: Electrically Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mounting and includes an auto overload protection system with Class B insulation. It is rated for continuous duty at 50/60 Hz and is suitable for 3-phase power only. The overall motor length is 12.89 inches, and the nameplate includes a wiring diagram for easy installation. It is compatible with multiple cross-reference models including P63SYFGN-1577, HD56FL651, 40LW35, HD56FE652, and 5K49MN4250FZ. The motor can also operate at 190/380V 50Hz with a 1.0 service factor.

Cross Reference

• Carrier, Bryant, Payne motor HD56FL652 56 Frame
• Cross Ref: P63SYFGN-1577, HD56FL652, HD56FL651, 40LW35, HD56FE652, 5K49MN4250FZ, 1419

Warranty

1 Year Manufacturer Warranty
