Y364 Marathon 1 hp 1800 RPM 3-Phase 56C Frame TEFC (rigid base) 230/460V Marathon Motor

Y364 Marathon 1 hp 1800 RPM 3-Phase 56C Frame TEFC (rigid base) 230/460V Marathon Motor

This Marathon 1 horsepower, 1800 RPM, three-phase electric motor is designed for industrial applications requiring reliable and efficient power. It is suitable for replacing or upgrading existing motors with a NEMA 56C frame and TEFC enclosure, commonly used in pumps, fans, and machinery.

Key Specifications

• Horsepower: 1 hp
• RPM: 1800
• Voltage: 230/460 V
• Amperage: 3.2/1.6 A
• Enclosure: Totally Enclosed Fan-Cooled (TEFC)
• Frame / Diameter: NEMA 56C
• Shaft Dimensions: 5/8" diameter x 1 7/8" length, keyed shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base and a C-face mount with four threaded bolt holes spaced 5 7/8" on center across the shaft, allowing easy attachment of pumps or gear heads. It is inverter (vector) duty rated with a 1000:1 constant torque capability. The motor includes a wiring diagram on the nameplate for straightforward electrical connections.

Warranty

1 Year Manufacturer Warranty
