4958 Nidec 3/4 hp 1140 RPM 575V 56YZ Frame (No Base) 1-Speed OAO 3-Phase Commercial Condenser Motor

4958 Nidec 3/4 hp 1140 RPM 575V 56YZ Frame (No Base) 1-Speed OAO 3-Phase Commercial Condenser Motor

SKU:
4958
Weight:
27.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $463.00
Now: $413.50
Adding to cart… The item has been added
  • 3/4 hp 1140 RPM, 1.2 amps 575V Volts 60 Hz 3-Phase Motor
  • NEMA 56YZ Frame, Rolled Steel, Flat Shaft 5/8" Diameter x 4 7/8" long
  • Service Factor = 1.0, Overload Protection: Auto
  • Band Mount, Ball Bearings, Class B Insulation, Rev
  • 1 Year Manufacture Warranty

Commercial Condenser Fan Motor. Wiring diagram on motor name plate. OAO = Open Air-Over, P063GEV4958015B

!
