2246 Nidec | 5" Condenser Fan Motor 1/5 hp 1075 RPM, 208-230 Volts

2246 Nidec 5" Condenser Fan Motor – 1/5 hp, 1075 RPM, 208-230 Volts

This 2246 Nidec condenser fan motor is designed as a direct replacement for models such as 5KCP29HCA326S and K48HXFPH-3956. It is primarily used in residential outdoor condenser fan and heat pump units up to 3.5 tons, providing reliable and efficient operation.

Key Specifications

• Horsepower: 1/5 hp
• RPM: 1075
• Voltage: 208-230 V
• Amperage: 1.6 A
• Frame / Diameter: 5"
• Shaft Dimensions: 1/2" x 3"
• Rotation: Reversible
• Bearings: Ball bearings

Product Features & Fitment

This motor features continuous duty air-over design with automatic overload protection, ensuring durability and safety during operation. It is intended for vertical shaft down applications and comes with 42" leads for easy wiring. A 5 MFD capacitor (part #5DV) is required for proper installation and operation.

Cross Reference

• 5KCP29HCA326S, K48HXFPH-3956. Applications: Designed for use in residential outdoor condenser fan and heat pump units (primarily up to 3.5 tons)

Warranty

1 Year Manufacturer Warranty
