FD5CM2K18 Nidec | 5 hp 1800 RPM 184T Frame TEFC (Farm Duty) 230V

FD5CM2K18 Nidec | 5 hp 1800 RPM 184T Frame TEFC (Farm Duty) 230V

This Nidec FD5CM2K18 motor is a 5 horsepower, 1800 RPM agricultural motor designed for farm duty applications. It serves as a reliable replacement for equipment requiring a 230V, 60Hz power supply with a keyed shaft and totally enclosed fan-cooled (TEFC) design.

Key Specifications

• Horsepower: 5 hp
• RPM: 1800
• Voltage: 230 V
• Amperage: 22.0 A
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• Frame / Diameter: NEMA 184T
• Shaft Dimensions: 1 1/8" diameter x 2 3/4" length
• Rotation: Electrically Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a manual overload protection system and is rated for continuous duty at 40°C ambient temperature with a service factor of 1.0. Its keyed shaft and NEMA 184T frame ensure compatibility with standard farm equipment mounts. The TEFC enclosure provides protection against dust and moisture, making it suitable for agricultural environments.

Warranty

1 Year Manufacturer Warranty
