- 5 hp 3600 RPM, 19.8 amps 230 Volts 60hz. single Phase Motor
- NEMA 184TC Frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
- Service Factor: 1.15 - overload protection = Manual
- Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a single phase Electric motor with a C-face mount. Motor has rigid base with C-Face mount. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 7 1/4" on center measured across the shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled.
P184K34FK2D, 131632.00
