8P7P2C Nidec 7 1/2 hp 1800 RPM 213T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor

SKU:
8P7P2C
Weight:
160.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,130.00
Now: $1,008.50
Adding to cart… The item has been added
  • 7 1/2 hp 1800 RPM, 9.1 amps 460 Volts 60 Hz Three Phase Motor
  • NEMA 213T Cast Iron Frame, Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 5 Year Manufacture Warranty, 3 year on inverter power

Corrosion resistant inverter duty motor is designed for use in petro-chemical and similar industries. Self-Certified Class 1, Division 2, Groups A, B, C, and D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. HB95
