Bison 011-190-4013 Gear Motor 1/20 hp, 139 RPM 24VDC

Bison 011-190-4013 Gear Motor 1/20 hp, 139 RPM 24VDC

SKU:
011-190-4013
Availability:
Bison is requiring minimum qty purchases, with a lead time of 12 weeks to manufacture the motors.
Weight:
8.00 LBS
Minimum Purchase:
5 units
Shipping:
Free Shipping
Confirmations:
All purchases understand the lead time requirements, we will not be sending out update emails.
Was: $677.38
Now: $541.90
Adding to cart… The item has been added
  • 100 Series DC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 20 inch pounds
  • Over Hung lbs. = 220
  • Rotation = Reversible
  • 1/20 hp, 139 RPM, 2.4 amps, 24 Volts DC
  • TENV Enclosure, Keyed Shaft, Ball Bearings

Optional Accessories: P198-100-9111 Junction Box, P125-100-9998 Mounting Plate. Replacement Brush Set # P158-200-2615. Permanent Magnet motor, Insulation Class B; Finish: Powder-coat gloss black; Brushes: Replaceable; Gearhead Specifications: Housing - Precision machined die cast aluminum; Shafts - Hardened steel; Gearing: Hardened Steel worm. Forged bronze gear; Lubrication: Lifetime oil bath, sealed and gasketed; Any angle mount; Bearings - Ball and Needle Bearings. Can use with Leeson speed control 175290.

!
