Bison 011-348-4015 Gear Motor 1/4 hp 121 RPM 90VDC

Bison 011-348-4015 Gear Motor 1/4 hp 121 RPM 90VDC

SKU:
011-348-4015
Availability:
Bison is requiring minimum qty purchases, with a lead time of 12 weeks to manufacture the motors.
Weight:
20.00 LBS
Minimum Purchase:
5 units
Shipping:
Free Shipping
Confirmations:
All purchases understand the lead time requirements, we will not be sending out update emails.
Was: $840.46
Now: $672.37
Adding to cart… The item has been added
  • 348 Series DC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 125 inch pounds
  • Over Hung lbs. = 250
  • 2 Stage
  • Rotation = Reversible
  • Rear tapped hole in shaft for encoder mount.
  • 1/4 hp 121 RPM, 2.51 amps, 90 Volts DC
  • TENV Enclosure, Keyed Shaft, Ball Bearings

Optional Accessories: P198-300-0000 Junction Box. Permanent Magnet motor, Insulation Class B; Finish: Powder-coat gloss black; Brushes: Replaceable; Rear tapped hole in shaft for encoder mount. Gearhead Specifications: Housing - Precision machined die cast aluminum; Shafts - Hardened steel; Gearing: Hardened Steel worm. Forged bronze gear; Lubrication: Lifetime oil bath, sealed and gasketed; Any angle mount; Bearings - Ball and Needle Bearings. Suggested replacement reference for: Baldor GPP7453. Can use with Leeson speed control 174307, 174308.

!
