Bison Gear Motors
Bison 016-101-0010 Gear Motor 1/20 hp 154 RPM 115V 60HZ.
(No reviews)
Write a Review
Write a Review
Bison Gear Motors
Bison 016-101-0010 Gear Motor 1/20 hp 154 RPM 115V 60HZ.
$658.13
$526.50
SKU
016-101-0010
UPC
8.45E+11
Availability
Bison is requiring minimum qty purchases, with a lead time of 12 weeks to manufacture the motors.
Minimum Purchase:
5 units
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
Confirmations
All purchases understand the lead time requirements, we will not be sending out update emails.
Voltage
115V
Horsepower
1/20 HP
RPM
154
Enclosure
TENV
Hertz
60 Hz
Amperage
62 Amps
Bearings
Ball Bearings
- 100 Series AC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
- Torque 20 inch pounds; Over Hung lbs. = 218
- Rotation = Reversible; Junction Box Included
- 1/20 hp 154 RPM, .62 amps, 115 VAC
- TENV Enclosure, Keyed Shaft, Ball Bearings
Gearhead Specifications: Housing: Precision machined die cast aluminum. Lubrication: Lifetime oil bath, sealed and gasketed. Shafts: Hardened steel. Mounting: Face (any angle) or optional footplate. Gearing: 1st stage helical metal, balance spur metal. Bearings: Needle bearings on output shaft. P125-100-9998 Optional Bison Gearmotor Mounting Bracket. One Year Manufacture Warranty. Opening motor voids the warranty. Dayton equivilient 6a196, Baldor equivilent GCP24140.
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| Confirmations | All purchases understand the lead time requirements, we will not be sending out update emails. |
| Voltage | 115V |
| Horsepower | 1/20 HP |
| RPM | 154 |
| Enclosure | TENV |
| Hertz | 60 Hz |
| Amperage | 62 Amps |
| Bearings | Ball Bearings |
