Bison 016-246-4019 Gear Motor 1/4 hp 88 RPM 115/230V 60/50 HZ.
Bison 016-246-4019 Gear Motor 1/4 hp 88 RPM 115/230V 60/50 Hz
The Bison 016-246-4019 is a 246 Series AC parallel shaft gear motor designed for versatile industrial applications. It serves as a reliable replacement motor with a permanent split capacitor design, suitable for both 60 Hz and 50 Hz power supplies.
Key Specifications
- Horsepower: 1/4 hp
- RPM: 88
- Voltage: 115/230 VAC
- Amperage: 2.35/1.25 amps
- Enclosure: TEFC (Totally Enclosed Fan Cooled)
- Rotation: Reversible
- Bearings: Ball bearings
Product Features & Fitment
This gear motor features a precision-machined die-cast aluminum gearhead with AGMA class 9 heat-treated steel gearing, including a first-stage helical metal gear and balanced spur metal gears. The shaft is keyed and made of hardened steel, supported by needle and thrust ball bearings. Lubrication is provided by a sealed, gasketed lifetime oil bath. Mounting options include face mounting at any angle or footplate installation, allowing flexible integration into existing systems. Availability is subject to factory stock; please contact for current availability.
Warranty
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| Confirmations | All purchases understand the lead time requirements, we will not be sending out update emails. |
| Voltage | 115/230V |
| Horsepower | 1/4 HP |
| Enclosure | TEFC |
| Hertz | 60/50 Hz |
| Amperage | 2.35/1.25 Amps |
| Bearings | Ball Bearings |
