C3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (Vertical) 208-230/460V TEFC 3-Phase C-Face Motor
C3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (Vertical) 208-230/460V TEFC 3-Phase C-Face Motor
C3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (Vertical) 208-230/460V TEFC 3-Phase C-Face Motor
C3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (Vertical) 208-230/460V TEFC 3-Phase C-Face Motor

Nidec

C3P2DCR Nidec 3 hp 1800 RPM 182TC Frame (Vertical) 208-230/460V TEFC 3-Phase C-Face Motor

(No reviews) Write a Review
$954.50
$852.38
SKU C3P2DCR
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182TC
Enclosure TEFC
Hertz 50/60 Hz
Amperage 8.8/3.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 3 hp 1800 RPM, 9.6-8.8/3.9 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 182TC cast iron frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Vertical C-Face Mount, Regreasable Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Three phase motor designed for chemically corrosive environments with either 50 or 60 Hz power. Inverter Duty. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DW71

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182TC
Enclosure TEFC
Hertz 50/60 Hz
Amperage 8.8/3.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Duty Inverter Duty
!
