This Carrier condenser fan motor is a direct replacement designed for HVAC condenser units, compatible with Carrier and several other OEM models. It delivers reliable 1/4 horsepower performance at 1100 RPM with a single-speed operation, suitable for residential and commercial air conditioning systems.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1100
• Voltage: 208-230V
• Amperage: 1.5 amps
• Enclosure: TEAO (Totally Enclosed Air Over)
• Frame / Diameter: 5-5/8" body diameter
• Shaft Dimensions: 1/2" diameter x 3.5" length
• Rotation: CCW shaft end
• Bearings: Sleeve bearings

Product Features & Fitment

This motor requires a 5 MFD/370VAC run capacitor (not included) for proper operation; replacement capacitors are recommended to ensure optimal performance. It features 50" leads and an automatic thermal reset for motor protection. The motor case length measures 4.62", and it is designed to fit as a suggested replacement for Carrier models HC39AE209 and HC39AE209A, as well as compatible GE Genteq and Nidec US Motor part numbers.

Cross Reference

• Carrier HC39AE209, HC39AE209A
• GE Genteq 3S033, 5KCP39FGZ039S, 5KCP39FGR560S
• Nidec US Motor K55HXKMU-0210, K055KMU0210011B

Warranty

1 Year Manufacturer Warranty
