D32P2B2 Nidec 1 1/2 hp 1800 RPM 145T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor

D32P2B2 Nidec 1 1/2 hp 1800 RPM 145T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor

This Nidec 1 1/2 horsepower electric motor is designed for general-purpose industrial applications such as pumps, fans, and compressors in environments with minimal contaminants. It serves as a reliable replacement motor featuring a rigid base mount and open drip proof enclosure for efficient operation.

Key Specifications

• Horsepower: 1 1/2 hp
• RPM: 1800
• Voltage: 230/460V
• Amperage: 4.2/2.1 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 145T Rolled Steel Frame
• Shaft Dimensions: 7/8" Diameter x 2 1/4" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base mount for secure installation and includes a keyed shaft for reliable coupling. It is equipped with Class F insulation and is designed for three-phase 60 Hz power supply. Wiring diagrams are provided on the motor nameplate to assist with proper electrical connections.

Warranty

1 Year Manufacturer Warranty
