GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V
GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V

Marathon

GT0816 Marathon 7 1/2 hp 1800 RPM 3-Phase 213T Frame ODP (rigid base) 200V

(No reviews) Write a Review
$1,113.20
$914.25
SKU GT0816
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
Voltage 200V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 213T
Enclosure ODP
Hertz 60 Hz
Amperage 22.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 7 1/2 hp 1800 RPM, 22.8 amps 200 Volts 60hz. Three Phase
  • NEMA 213T frame
  • Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

General purpose motors are for use in situations not having special requirements. This is a three phase motor with a rigid base mount. Shaft has keyway. Wiring diagram on motor name plate. ODP = Open Drip Proof.

Replaces Century E316M2

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
Voltage 200V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 213T
Enclosure ODP
Hertz 60 Hz
Amperage 22.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
