Klauber RV Slide Out Motor K01531D400

Klauber RV Slide Out Motor K01531D400

This brand new direct OEM replacement motor is designed for RV slide-out applications, providing reliable performance and durability. It replaces several models including Adacel P1DC1259RB, Von Weise V05726AP88, and Klauber K01389A400, ensuring compatibility with a range of existing systems.

Key Specifications

• Horsepower: 1/5 HP
• RPM: 70
• Voltage: 12 Volts DC
• Amperage: 27 Amps
• Shaft Dimensions: 5/8" x 1-1/2" with crosshole
• Rotation: Reversible, Intermittent Duty

Product Features & Fitment

Manufactured by Klauber Gear in the USA, this motor includes an electric brake and features a 3-bolt face mount for secure installation. Note that the power connector is not included; you will need to reuse your existing plug connector during installation.

Cross Reference

• S
• Adacel P1DC1259RB, P1DB, P1DB1259
• Von Weise V05726AP88, V05726AA88
• Klauber K01389A400, K01531D400
• Replaces M-01C, X7X1A1
