Marine Air Conditioning Pump - 300 Gallon Per hour flow rate
- Inlet 3/8" FPT & 3/4" MPT
- Outlet 1/4" MPT Outlet
- 1/35 hp; 3450 RPM; .92 Amps, 115V 50/60hz.
- 5 GPM; 13' Max. Head Feet
- Max Internal Pressure: 25 PSI / 1.7 bar
- Max Internal Temperature: 130 °F / 54 °C
- 6' Power Cord
- One Year Warranty
March Part No. 0125-0057-0200
Wet End: Polypropylene (Front and Rear Housing, Impeller), Viton (O-Ring), 316 Stainless Steel (Shaft, Cooling Tube), Buna N (Cooling Tube Seal), Ceramic (Thrust Washer), Ceramic Magnet
Replaces the following manufactures pump model - This pump is single voltage 115v, so please verify your existing voltage to make sure your selecting the correct pump.
Adler Barbour D8150
Aqua Air AQPM-02
Cruisair PM250
Lunair WPC250
Marine Air P400
Marine Air PML250
Technicold TE-250
Perfect for Applications Including
The most common application for the LC-2CP-MD Magnetic Drive Pump is for marine air conditioning and fountains.
Great for Chemicals Including
The LC-2CP-MD has pumped Fresh Water and Salt Water. This pump may have to be modified to pump specific gravities, viscosities, or elevated temperatures different then ambient water.
Summary
March Pump’s industrial LC-2CP-MD is an American submersible seal-less centrifugal magnetic drive pump. It is capable of generating a maximum flow of 5 gallons per minute at 1 foot, and its maximum head is 13 Feet (5.5PSI). The LC-2CP-MD pump may be used submerged or not submerged. The standard wet end (the materials that come into contact with the solution) is composed of Polypropylene, Viton, Buna N, Stainless Steel, Ceramic, and Ceramic Magnet. When submerged, Epoxy, Buna N, and the Cord are also in contact with the solution. The inlet connection is 3/8 inch female pipe thread and 3/4 inch male pipe thread, and the outlet is 1/4 inch male pipe thread. The standard motor is a 1 Phase 115V 0.02 Horsepower motor, which can be run on either 50 or 60 hertz (there are performance differences between the hertz options). The maximum internal pressure the pump can tolerate is 25PSI, and the maximum liquid temperature is 130 Fahrenheit or 54 Celsius. The March LC-2CP-MD centrifugal magnetic drive pump is capable of handling fresh water, salt water, and mild chemicals. To determine if the March LC-2CP-MD is suitable for your application, please contact March Pump.
For application assistance, contact March Pump.
