- 1/15 hp, 9 RPM, 0.9 amps, 115 Volts AC
- Gear Ratio = 180
- Torque 100 inch pounds
- Over Hung Pounds = 155
- Rotation = Reversible
- TEFC, Keyed Shaft, Ball Bearings
One Year Manufacture Warranty. Features: This worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation. Precision machined aluminum housings are used. Gearbox has ball bearings. The housing is sealed and lubrication is permanent with an oil bath. The output shaft is field interchangeable from left hand style to right hand style by reassembly. Optional mounting bracket # M1760003 and optional conduit box # M1760021 available.
M1125127.00 CM31P17FZ1A
Suitable replacement for Baldor GCP24114, Bison 016-103-2186, Bodine 0449 - Please double check the specs to make sure it will work for your application
Some of the differences are but not limited to the following, please cross check your existing motor specs, shaft and mounting to make sure the replacement Leeson will interchange with your existing equipment
Baldor - Leeson is fan cooled
Bison - Leeson is fan cooled
Bodine - Leeson is fan cooled
