- 1/20 hp, 20 RPM, 0.54 amps, 90 Volts DC
- Gear Ratio = 90
- Torque 100 inch pounds
- Over Hung Pounds = 155
- TENV - Totally Enclosed Non Ventilated
- Class F Insulation; Service Factor 1.0
- Optional conduit box and PZ gearmotor mounting bracket available
- Shaft 1/2" x 1"; Rotation = Reversible
- Keyed Shaft; Ball Bearings
- One Year Manufacture Warranty.
Optional "L" bracket # M1760003 and Conduit Box # M1760021 are available. Features: Precision machined in-line steel gears, with a first stage steel helical gear followed by spur-type gears. Lubrication is permanent semi-fluid grease, reducing possibility of leakage. Output shafts have needle bearings for high load capacities. Shafts are hardened steel. Can use with Leeson speed control 174307, 174308.
985.622G, M1115000.00
Suitable replacement for Baldor GPP232110, Bison 011-190-0096, Bodine 0162 - Please cross check your existing motor specs, shaft and mounting to make sure the replacement Leeson will interchange with your existing equipment
