- 1/8 hp, 29 RPM, 2.9/1.45 amps,115/230 Volts 50/60hz.
- Gear Ratio = 58
- Torque 270 inch pounds
- Over Hung Pounds = 327
- Rotation = Reversible
- TEFC, Keyed Shaft, Ball Bearings
One Year Manufacture Warranty. Features: This worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation. Precision machined aluminum housings are used. Gearbox has ball bearings. The housing is sealed and lubrication is permanent with an oil bath. IP55 Washdown Duty. White epoxy paint. Optional L Bracket # M1760011, Optional Conduit Box # 175893.
C42P17FZ1B, 096004.00
Suitable replacement for Baldor GCP25002 - Please cross check your existing motor specs, shaft and mounting to make sure the replacement Leeson will interchange with your existing equipment
