NPV0602C TECO-Westinghouse 60 HP 3600 RPM 364TSC 230/460V TEFC Vertical Severe Duty 3-Ph Motor

NPV0602C TECO-Westinghouse 60 HP 3600 RPM 364TSC 230/460V TEFC Vertical Severe Duty 3-Ph Motor

SKU:
NPV0602C
Availability:
Subject to Availability
Weight:
832.00 LBS
Width:
26.00 (in)
Height:
36.00 (in)
Depth:
28.00 (in)
Shipping:
Calculated at Checkout
Voltage:
230/460V
Horsepower:
60 HP
RPM:
3600
Phase:
Three Phase
Frame:
364TSC
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
128/64.2 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
C-Face
Duty:
Severe Duty
$5,082.57
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 60 hp 3600 RPM, 128/64.2 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 364TSC Frame, 3 1/2 x 1 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • C-Face, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

For use in Severe Duty Applications Having Explosive Gases. Certified for Class 1, Division 2, Groups B,C,D

!
