QT0756 TECO-Westinghouse 75 HP 1200 RPM 444T 230/460V TEFC 3-Phase Oil Well Pump Motor

SKU:
QT0756
Weight:
1,245.00 LBS
Shipping:
Calculated at Checkout
$9,377.91
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 75 hp 1200 RPM, 182/91.0 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 444T/405T Frame, 7 1/8 x 2 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Rodent Screens, 5% Minimum Slip
  • 1 Year Manufacture Warranty

Oil well pump motor for use on oil pumps. Also good for any application requiring NEMA Design D torques.
