T1CM2J14CR Nidec 1 hp 1800 RPM 143TC (No Base) 115/208-230V TEFC 1-Phase Motor

T1CM2J14CR Nidec 1 hp 1800 RPM 143TC (No Base) 115/208-230V TEFC 1-Phase Motor

SKU:
T1CM2J14CR
Weight:
32.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $759.00
Now: $677.30
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 14.0/6.9-7.0 amps 115/208-230 Volts 60 Hz Cap Start Single Phase Motor
  • NEMA 143TC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = Manual
  • C-Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor for pumps, conveyors, air compressors, and blowers. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. C063JEK5314015B

!
