U10R9C Nidec 10 hp 1800/900 RPM (2 speed) 256T Frame 460V TEFC Constant-Torque 3-Phase Electric Motor

U10R9C Nidec 10 hp 1800/900 RPM (2 speed) 256T Frame 460V TEFC Constant-Torque 3-Phase Electric Motor

SKU:
U10R9C
Weight:
238.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $2,365.00
Now: $2,111.20
Adding to cart… The item has been added
  • 10 hp 1800/900 RPM (2 speed), 12.7 amps 460 Volts 60 Hz Constant Torque Three Phase Motor
  • NEMA 254T frame Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.0, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

This 3-phase, one winding motor is designed for use in 2-speed applications requiring constant shaft torque.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. C877

!
