UJ25P1DP US Motors 25 hp 3600 RPM 3-phase 284JP Frame 208-230/460V Close-Coupled Pump Motor

UJ25P1DP US Motors 25 hp 3600 RPM 3-phase 284JP Frame 208-230/460V Close-Coupled Pump Motor

SKU:
UJ25P1DP
Weight:
280.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $2,734.00
Now: $2,441.00
Adding to cart… The item has been added
  • 25 HP 3600 RPM, 65.0-57.0/28.4 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 284JP Cast Iron Frame, JP stainless steel shaft
  • 1.25 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, FL49

!
