UN1T2BC Nidec 1 hp 1800 RPM 145TC (Rigid Base) 230/460V TENV Vector-Duty 3-Phase Motor

UN1T2BC Nidec 1 hp 1800 RPM 145TC (Rigid Base) 230/460V TENV Vector-Duty 3-Phase Motor

SKU:
UN1T2BC
Weight:
30.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $519.00
Now: $463.50
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 3.2/1.6 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145TC Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable C-Face motor for material handling, cranes and machine tools. 5000:1 constant torque from 0 to nominal motor rpm. NEMA design A. Encoder and brake provisions. Wiring diagram on motor name plate. TENV = Totally-Enclosed Non-Ventilated. FD93

!
