X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor
X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor
X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor
X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor
X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor
X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor

Marathon

X446 Marathon 0.6 hp 200-230/460V 1075 RPM OPAO 48Y Frame Canopy Condenser Fan Motor

(No reviews) Write a Review
$369.96
$322.46
SKU X446
UPC 7.23E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 200/230/460V
Horsepower 3/5 HP
RPM 1075
Frame 48Y
Hertz 60 Hz
Amperage 3.0/1.8 Amps
Bearings Ball Bearings
Insulation Class Class B
Adding to cart… The item has been added
Description
  • 0.6 hp 1075 RPM, 3.6-3.0/1.8 amps, 208-230/460 Volts 60 Hz, Permanent Split Capacitor (PSC)
  • NEMA 48Y Frame Keyed Shaft 1/2" Diameter x 4"
  • Service Factor = 1.0, Thermal Protection = Automatic
  • No Base, Reversible, Ball Bearings, Class B insulation
  • 1 Year Manufacture Warranty

Condenser Fan Motors are used in air conditioning coolant condenser units usually found outdoors. Shaft may be vertical or horizontal. OPAO = Open Air Over so motor must be in air-stream. 048A11O1643





Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 200/230/460V
Horsepower 3/5 HP
RPM 1075
Frame 48Y
Hertz 60 Hz
Amperage 3.0/1.8 Amps
Bearings Ball Bearings
Insulation Class Class B
!
