Fasco D114 Motor | 1/12 hp 1550 RPM CW 4.4" Diameter 115/230 Volts

Fasco D114 Motor | 1/12 hp 1550 RPM CW 4.4" Diameter 115/230 Volts

The Fasco D114 is a shaded pole motor designed for unit heater applications. It serves as a reliable replacement motor featuring a totally enclosed, air over design to ensure durability and efficient operation.

Key Specifications

• Horsepower: 1/12 hp
• RPM: 1550
• Voltage: 115/230 Volts, 60 Hz
• Amperage: 2.5/1.3 Amps
• Enclosure: Totally Enclosed, Air Over
• Frame / Diameter: 4.4" Diameter
• Shaft Dimensions: 3/8" diameter x 3" length
• Rotation: Clockwise (CWSE)
• Bearings: Sleeve Bearings

Product Features & Fitment

This motor features a stud mount with a bolt circle diameter of 3.89" for secure installation. The motor length excluding the shaft measures 4 1/8", making it compatible with standard unit heater assemblies. Its shaded pole design ensures quiet and efficient operation in HVAC systems.

Warranty

1 Year Manufacturer Warranty
