1090 Nidec | 1/16 hp 1100 RPM 3-Speed 115V; 5.0" Blower Motor
1090 Nidec | 1/16 hp 1100 RPM 3-Speed 115V; 5.0" Blower Motor
1090 Nidec | 1/16 hp 1100 RPM 3-Speed 115V; 5.0" Blower Motor
1090 Nidec | 1/16 hp 1100 RPM 3-Speed 115V; 5.0" Blower Motor

Nidec

1090 Nidec | 1/16 hp 1100 RPM 3-Speed 115V; 5.0" Blower Motor

(No reviews) Write a Review
$408.25
$365.01
SKU 1090
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/16 HP
RPM 1100
Type Permanent Split Capacitor
Amperage 0.80 Amps
Bearings Sleeve Bearings
Speeds 3-Speed
Insulation Class Class B
Rotation Counter-Clockwise
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/16 hp 1100 RPM 3-Speed 115V 0.80 amps
  • Shaft 10.0" x 0.5" x 9.9"
  • Rotation: CCW shaft end
  • 5.0" Diameter
  • Motor case length 3.81"
  • Sleeve bearings
  • Resilient base Mount
  • 5MFD 370V Capacitor REQUIRED (Our Part #5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Open Enclosure; Class B Insulation; 40C Ambient Temperature; 44" Leads, 60 Hertz. Application: Furnace, Heat Pumps. K048TBD3640013B: Suggested aftermarket replacement for Trane K48HXBJA0956, X70500149-04, X70500149-01, 5KSP29KD1507S, Fasco D1090

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/16 HP
RPM 1100
Type Permanent Split Capacitor
Amperage 0.80 Amps
Bearings Sleeve Bearings
Speeds 3-Speed
Insulation Class Class B
Rotation Counter-Clockwise
Duty Continuous Duty
!
