1678 Nidec | 1/16 hp 850 RPM 3-Speed 277V; 5" Blower Motor

1678 Nidec | 1/16 hp 850 RPM 3-Speed 277V; 5" Blower Motor

This 1/16 horsepower blower motor is designed for heat pump and furnace applications, offering reliable performance as a suggested replacement for Trane models including K48HXCNN1468 and X70500269-01. It operates at 850 RPM with a 3-speed setting and is compatible with 277V power supplies.

Key Specifications

• Horsepower: 1/16 hp
• RPM: 850
• Voltage: 277V
• Amperage: 0.50 amps
• Enclosure: Open
• Frame / Diameter: 5" diameter
• Shaft Dimensions: 7.5" length x 1/2" diameter
• Rotation: CCWSE (Counterclockwise Shaft End)
• Bearings: Sleeve Bearings

Product Features & Fitment

This motor features a permanent split capacitor design with automatic overload protection, suitable for continuous duty operation in ambient temperatures up to 40°C. It includes a 4 MFD capacitor and comes with 16" leads for easy electrical connections. The motor case length measures 4.062", facilitating straightforward installation in compatible HVAC systems.

Cross Reference

• Trane K48HXCNN1468, X70500269-01, MOT2852, K048TAW3623013B, 5KSP29DK1507S

Warranty

1 Year Manufacturer Warranty
