1694 Nidec | 1/2 hp 1625 RPM 3-Speed 115V; 5.6" Blower Motor

1694 Nidec | 1/2 hp 1625 RPM 3-Speed 115V; 5.6" Blower Motor

This 1/2 horsepower blower motor by Nidec is designed for HVAC applications requiring reliable, multi-speed operation. It serves as a direct replacement motor with a reversible shaft rotation and is suitable for continuous duty in open air environments.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1625
• Voltage: 115V
• Amperage: 5.5 amps
• Frame / Diameter: 5.6" diameter
• Shaft Dimensions: 0.5" x 5.5"
• Rotation: Reversible
• Bearings: Sleeve Bearings
• Enclosure: Open Air Over

Product Features & Fitment

This motor features a resilient ring mount for secure installation and requires a 20MFD 370V capacitor (Nidec Part #20DV) for proper operation. It includes 36" leads and is built with Class A insulation for operation in ambient temperatures up to 40°C. The motor is a permanent split capacitor type with automatic overload protection, ensuring durability and continuous duty performance.

Warranty

1 Year Manufacturer Warranty
