D12CP2PH9 Nidec | 1/2 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

D12CP2PH9 Nidec | 1/2 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

SKU:
D12CP2PH9
Availability:
Subject to availability
Weight:
18.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $354.00
Now: $315.90
Adding to cart… The item has been added
  • 1/2 hp 1800 RPM, 5.0/2.6 amps 115/230 Volts 60hz. Single Phase Motor
  • NEMA 56H Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Capacitor Start
  • Service Factor: 1.25, Overload protection = None
  • Reversible, Resilient Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. ODP = Open Drip Proof
