sale
Nidec
D1CP2PH9 Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor
(No reviews)
Write a Review
Write a Review
Nidec
D1CP2PH9 Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor
$549.70
$490.48
SKU
D1CP2PH9
Availability
Subject to availability
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
115/230V
Horsepower
1 HP
RPM
1800
Phase
Single Phase
Frame
56H
Enclosure
ODP
Hertz
60 Hz
Amperage
8.8/4.4 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class B
D1CP2PH9 Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor
This general-purpose single-phase electric motor is designed for a variety of industrial and commercial applications. It serves as a reliable replacement motor with a robust build suitable for equipment requiring a 1 hp, 1800 RPM motor.
Key Specifications
- Horsepower: 1 hp
- RPM: 1800
- Voltage: 115/230 V
- Amperage: 8.8/4.4 A
- Enclosure: Open Drip Proof (ODP)
- Frame / Diameter: NEMA 56H
- Shaft Dimensions: Keyed shaft, 5/8" diameter x 1 7/8" length
- Rotation: Reversible
- Bearings: Ball bearings
Product Features & Fitment
This motor features a capacitor start and a service factor of 1.15, designed for efficient operation without built-in overload protection. It includes a resilient base mount for stable installation and a wiring diagram located on the motor nameplate for easy setup. The Class B insulation rating ensures durability in typical operating environments.
Warranty
1 Year Manufacturer Warranty
1 Year Manufacturer Warranty
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 115/230V |
| Horsepower | 1 HP |
| RPM | 1800 |
| Phase | Single Phase |
| Frame | 56H |
| Enclosure | ODP |
| Hertz | 60 Hz |
| Amperage | 8.8/4.4 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class B |
