D1CPA2PH Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor
D1CPA2PH Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor
D1CPA2PH Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor
D1CPA2PH Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

Nidec

D1CPA2PH Nidec | 1 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

(No reviews) Write a Review
$757.85
$677.12
SKU D1CPA2PH
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1 HP
RPM 1800
Phase Single Phase
Frame 56H
Enclosure ODP
Hertz 60 Hz
Amperage 8.8/4.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Duty Continuous Duty
Cross Reference D1CA2JH, T063CPA2163012B,  5KC49PN0161X, Marathon G935, 56C17D5304, MG935, C182, MC182, C682, MC682, 110000.00, E110000.00
Adding to cart… The item has been added
Description
  • 1 hp 1800 RPM, 8.8/4.4 amps 115/230 Volts 60hz. Single Phase Motor
  • NEMA 56H Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • ODP; Service Factor: 1.15, Overload protection = Auto
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Continuous Duty.  Wiring diagram on motor name plate. ODP = Open Drip Proof

T063CPA2163012B
Specifications
Voltage 115/230V
Horsepower 1 HP
RPM 1800
Phase Single Phase
Frame 56H
Enclosure ODP
Hertz 60 Hz
Amperage 8.8/4.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Duty Continuous Duty
Cross References

D1CA2JH, T063CPA2163012B,  5KC49PN0161X, Marathon G935, 56C17D5304, MG935, C182, MC182, C682, MC682, 110000.00, E110000.00

!
