1940 Nidec | 1/2 hp 825 RPM 1-Speed 115V; 5.6" Yoke Mount Fan Motor
1940 Nidec | 1/2 hp 825 RPM 1-Speed 115V; 5.6" Yoke Mount Fan Motor
1940 Nidec | 1/2 hp 825 RPM 1-Speed 115V; 5.6" Yoke Mount Fan Motor
1940 Nidec | 1/2 hp 825 RPM 1-Speed 115V; 5.6" Yoke Mount Fan Motor

Nidec

1940 Nidec | 1/2 hp 825 RPM 1-Speed 115V; 5.6" Yoke Mount Fan Motor

(No reviews) Write a Review
$478.40
$427.11
SKU 1940
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/2 HP
RPM 825
Enclosure TEAO
Type Permanent Split Capacitor
Amperage 6.4 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.0
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/2 hp 825 RPM 1-Speed 6.4 amps 115V
  • Shaft 5/8" x 2.375"
  • Rotation: CW shaft end
  • 5.6" Diameter
  • Motor case length 7.0"
  • Ball Bearings; TEAO
  • Class B Insulation; Service Factor 1.0
  • Yoke Mount - Pedestal Mount
  • Includes 30 MFD capacitor
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally Enclosed Air Over Enclosure; 40C Ambient Temperature; 60 Hertz. K055NFA7278021B. Ventilation Yoke Mount Fan Motor. Designed to meet manufacturer’s requirements for air circulators where motor is mounted directly to fan column. For direct drive exhaust and vent fans in poultry and livestock houses.

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/2 HP
RPM 825
Enclosure TEAO
Type Permanent Split Capacitor
Amperage 6.4 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.0
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
!
