FD13SM2DZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor
FD13SM2DZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor
FD13SM2DZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor
FD13SM2DZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor

Nidec

FD13SM2DZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor

(No reviews) Write a Review
$319.70
$285.66
SKU FD13SM2DZYR
UPC 6.63E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/3 HP
RPM 1800
Phase Three Phase
Frame 56Y
Enclosure TEFC
Amperage 2.0/1.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Duty continuous duty
Adding to cart… The item has been added
Description
  • 1/3 hp 1800 RPM, 2.0/1.0 amps, 208-230/460V Three Phase
  • 56Y Frame - 1/2" Diameter x 1.75" w/flat
  • Face Mount
  • TEFC Totally Enclosed Fan Cooled; Service Factor = 1.0
  • Ball Bearings; Reversible Rotation
  • Manual Overload Protection; Class F Insulation
  • 40C Ambient Temp, continuous duty
  • 1 Year Manufacture Warranty

Auger Drive Motor. Designed for direct drive poultry and swine feeding systems.
Model P063FPE4275015B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/3 HP
RPM 1800
Phase Three Phase
Frame 56Y
Enclosure TEFC
Amperage 2.0/1.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Duty continuous duty
!
