FD1PM2DZYR Nidec | 1 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor
FD1PM2DZYR Nidec | 1 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor
FD1PM2DZYR Nidec | 1 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor
FD1PM2DZYR Nidec | 1 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor

Nidec

FD1PM2DZYR Nidec | 1 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor

(No reviews) Write a Review
$447.35
$399.51
SKU FD1PM2DZYR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Frame 56Y
Enclosure TEFC
Amperage 3.3/1.5 Amps
Bearings Ball Bearings
Insulation Class Class B
Rotation Reversible
Duty continuous duty
Adding to cart… The item has been added
Description
  • 1 hp 1800 RPM, 3.3/1.5 amps, 208-230/460V Three Phase
  • 56Y Frame - 5/8" Diameter x 2.1" Keyed Shaft with Flat
  • Face Mount
  • TEFC Totally Enclosed Fan Cooled; Service Factor = 1.15
  • Ball Bearings; Reversible Rotation
  • Manual Overload Protection; Class B Insulation
  • 40C Ambient Temp, continuous duty
  • 1 Year Manufacture Warranty

Auger Drive Motor. Designed for direct drive poultry and swine feeding systems.
Model P063DZZ1488015B

Specifications
Voltage 208/230/460V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Frame 56Y
Enclosure TEFC
Amperage 3.3/1.5 Amps
Bearings Ball Bearings
Insulation Class Class B
Rotation Reversible
Duty continuous duty
!
