FD1PM2DZYR Nidec | 1 hp 1800 RPM 56Y Frame TEFC 208-230/460V Nidec Electric Auger Drive Motor

SKU:
FD1PM2DZYR
Weight:
36.00 LBS
Shipping:
Calculated at Checkout
$270.47
  • 1 hp 1800 RPM, 3.3/1.5 amps, 208-230/460V Three Phase
  • 56Y Frame - 5/8" Diameter x 2.1" Keyed Shaft with Flat
  • Face Mount
  • TEFC Totally Enclosed Fan Cooled; Service Factor = 1.15
  • Ball Bearings; Reversible Rotation
  • Manual Overload Protection; Class B Insulation
  • 40C Ambient Temp, continuous duty
  • 1 Year Manufacture Warranty

Auger Drive Motor. Designed for direct drive poultry and swine feeding systems.
Model P063DZZ1488015B
