Fasco D1179 Motor | 1/30 hp 3000 RPM CW 3.3" diameter 115V (Bryant/Carrier)

Fasco D1179 Motor | 1/30 hp 3000 RPM CW 3.3" diameter 115V (Bryant/Carrier)

The Fasco D1179 is a compact 1/30 horsepower motor designed for HVAC applications, compatible with Bryant and Carrier systems. It serves as a reliable replacement for various OEM part numbers, ensuring seamless integration and performance.

Key Specifications

• Horsepower: 1/30 hp
• RPM: 3000
• Voltage: 115 V
• Amperage: 1.5 A
• Frame / Diameter: 3.3"
• Shaft Dimensions: 5/16" diameter x 2" length
• Rotation: Clockwise (SE)

Product Features & Fitment

This motor features a lug mount with two studs on the shaft end for secure installation. The motor length excluding the shaft measures 3.5 inches, making it suitable for compact spaces. It is a suggested replacement for multiple models including BDP P251-2916, Franklin 8251510360, JA1M086 series, JE1D010, HC27C8116, 7121-6805, Dayton 48GN72, and AO Smith/Century 579.

Cross Reference

• BDP P251-2916, Franklin 8251510360, JA1M086, JA1M086N, JE1D010, HC27C8116, 7121-6805. Dayton 48GN72. Replaces AO Smith/Century 579

Warranty

1 Year Manufacturer Warranty
