DL1026 Century 1/4 hp 1075 RPM 3-Speed 48 Frame 115V Direct Drive Furnace Motor

DL1026 Century 1/4 hp 1075 RPM 3-Speed 48 Frame 115V Direct Drive Furnace Motor

This Century 1/4 horsepower direct drive furnace motor is designed for residential HVAC applications, offering reliable performance and compatibility with most belly band mounting systems. It serves as a replacement motor for various furnace models requiring a 3-speed, 115V motor with reversible rotation.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1075
• Voltage: 115V
• Amperage: 4.5 amps
• Frame / Diameter: 48 Frame / 5.6" Diameter
• Shaft Dimensions: 1/2" x 4.5"
• Rotation: Reversible
• Bearings: Sleeve Bearings
• Enclosure: Permanent Split Capacitor Motor

Product Features & Fitment

This motor requires a 5MFD 370V capacitor (Part #5DV) for proper operation and includes 26" leads for easy wiring. It features a 3-speed design with automatic overload protection and continuous duty rating, suitable for ambient temperatures up to 40°C. The motor body length measures 4 5/16", and it can be mounted using belly band straps or stud mounts. Compatible belly band brackets include the Torsion Flex Bracket (3-Prong #2MEY7, 4-Prong #FM554) and Welded 3-Ring Bracket (#2MEV4). The motor also includes 2 1/4" resilient rings for vibration reduction and is designed for easy rotation changes.

Warranty

1 Year Manufacturer Warranty
