- 1/4 hp 1800 RPM, 3.1/1.5 amps 115/230 Volts 60hz. Single Phase Motor
- NEMA 48 Frame Keyed Shaft 1/2" Diameter x 1 7/8"
- ODP; Service Factor: 1.35, Overload protection = None
- Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a single phase electric motor. Continuous Duty. Wiring diagram on motor name plate. ODP = Open Drip Proof
T055CRL1540012B
