Nidec

BMU32S2AFCR Nidec | 1.5 hp 1800 RPM 56C Frame 208-230/460V TEFC Nidec C-Face Electric Brake Motor

(No reviews) Write a Review
$0.00
SKU BMU32S2AFCR
UPC 6.63E+11
Availability Subject to availability
Shipping Free Shipping
DISCONTINUED See Marathon D457A
Voltage 208/230/460V
Horsepower 1-1/2 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TEFC
Amperage 4.7/2.3 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description

BMU32S2AFCR HAS BEEN DISCONTINUED - PLEASE SEE MARATHON D457A

  • 1.5 hp 1800 RPM, 4.7/2.3 amps 208-230/460 Volts 3 phase Motor
  • NEMA 56C Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Face Mount-No Base
  • 10 Foot Pounds
  • Service Factor: 1.25, Overload protection = None
  • Reversible, Ball Bearings, Class F Insulation
  • TEFC = Totally Enclosed Fan-Cooled
  • 40C Ambient Temp.
  • 1 Year Manufacture Warranty

Unimount Brake Motor

Model CE55

Specifications
DISCONTINUED See Marathon D457A
Voltage 208/230/460V
Horsepower 1-1/2 HP
RPM 1800
Phase Three Phase
Frame 56C
Enclosure TEFC
Amperage 4.7/2.3 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting C-Face
!
