109103.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 24 Volts DC TEFC

109103.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 24 Volts DC TEFC

This Leeson 1.5 hp permanent magnet DC motor is designed for low voltage applications such as battery or solar-powered systems. It offers high starting torque and linear speed/torque characteristics, making it ideal for heavy load and dynamic braking operations.

Key Specifications

• Horsepower: 1.5 hp
• RPM: 1800
• Voltage: 24 Volts DC
• Amperage: 60 amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 56C Frame
• Shaft Dimensions: 7/8" diameter
• Bearings: Sealed ball bearings

Product Features & Fitment

The motor features a 56C face with a removable bolt-on base for flexible mounting options. It is reversible with a simple two-lead connection and compatible with Leeson speed control model 175291. The sealed ball bearings ensure durability and reliable operation in demanding environments.

Warranty

1 Year Manufacturer Warranty
