109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC

Leeson

109104.00 Leeson | 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC

(No reviews) Write a Review
$1,294.90
$1,097.33
SKU 109104
UPC 6.92E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 36V
Horsepower 1-1/2 HP
RPM 1800
Frame 56CZ
Enclosure TEFC
Amperage 36 Amps
Bearings Ball Bearings
Adding to cart… The item has been added
Description
  • 1.5 hp 1800 RPM 56CZ Frame 36 Volts DC TEFC
  • NEMA 56C Frame Low Voltage Motor 36 amps, 36VDC
  • 56C Face with Removable Bolt On Base; TEFC (Shaft = 7/8" diameter)
  • TEFC = Totally Enclosed Fan cooled
  • Permanent magnet DC motor
  • 1 Year Manufacture Warranty

Low voltage permanent magnet DC motors are suitable for installations having battery or solar powered operations. High starting torques for heavy load applications. Linear speed/torque characteristics over entire speed range. Capable of dynamic braking for faster stops. Motors have sealed ball bearings. Reversible-Simple 2-lead connection. Can use with Leeson speed control 175292.

C4D18FK4B, 109104.00

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 36V
Horsepower 1-1/2 HP
RPM 1800
Frame 56CZ
Enclosure TEFC
Amperage 36 Amps
Bearings Ball Bearings
!
