122074.00 Leeson | 1.5 hp 3600 RPM 143JM Frame ODP 230/460V

SKU:
122074
Weight:
38.00 LBS
Shipping:
Free Shipping
ON SALE:
DISCOUNTED PRICES AND FREE GROUND SHIPPING
Was: $608.00
Now: $515.60
Adding to cart… The item has been added
  • 1.5 hp 3600 RPM 143JM Frame, 3.8/1.9 amps 230/460V 60hz. Three Phase Motor
  • Close Coupled Pump Motor - Rigid Base
  • Open Drip Proof (ODP) - Service Factor = 1.15
  • Class F Insulation, No Overload Protection
  • Continuous duty
  • One Year Manufacture Warranty

Close Coupled Pump Motor. Designed for continuous duty service on close Coupled pumps. Motor has rigid base. Wiring diagram on motor name plate.

Leeson Model C143T34DK4A; 122074.00
Replaces Marathon GT0403, 143TTDR6007
