FD32CA1P14 Nidec | 1.5 hp 3600 RPM 143TZ 115/230V Aeration Fan Motor

SKU:
FD32CA1P14
Availability:
Subject to availability
Weight:
32.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $541.00
Now: $483.20
Adding to cart… The item has been added
  • 1.5 hp 3600 RPM, 17.4/8.7 amps, 115/230V 60 hz.
  • NEMA 143TZ Frame Shaft 7/8" x 2.25"; Reversible
  • .75" deep tapped hole in shaft with  1/4" - 20 threads
  • TEAO-Totally Enclosed Air Over; Service Factor = 1.0
  • Automatic Overload Protection
  • Class B Insulation; 50C Ambient Temp
  • One Year Manufacture Warranty.

Aeration Fan Motor. For air over applications or fans mounted directly on the motor shaft. Specifically designed for use on van axial crop dryers and aeration fans. Designed to be used within the airflow of the driven fan

Model C063JCA5265012B; Dayton 4K060
