FD32CA1P14 Nidec | 1.5 hp 3600 RPM 143TZ 115/230V Aeration Fan Motor
FD32CA1P14 Nidec | 1.5 hp 3600 RPM 143TZ 115/230V Aeration Fan Motor
FD32CA1P14 Nidec | 1.5 hp 3600 RPM 143TZ 115/230V Aeration Fan Motor
FD32CA1P14 Nidec | 1.5 hp 3600 RPM 143TZ 115/230V Aeration Fan Motor

Nidec

FD32CA1P14 Nidec | 1.5 hp 3600 RPM 143TZ 115/230V Aeration Fan Motor

(No reviews) Write a Review
$622.15
$555.68
SKU FD32CA1P14
UPC 6.63E+11
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1-1/2 HP
RPM 3600
Frame 143TZ
Enclosure TEAO
Hertz 60 Hz
Amperage 17.4/8.7 Amps
Insulation Class Class B
Adding to cart… The item has been added
Description
  • 1.5 hp 3600 RPM, 17.4/8.7 amps, 115/230V 60 hz.
  • NEMA 143TZ Frame Shaft 7/8" x 2.25"; Reversible
  • .75" deep tapped hole in shaft with  1/4" - 20 threads
  • TEAO-Totally Enclosed Air Over; Service Factor = 1.0
  • Automatic Overload Protection
  • Class B Insulation; 50C Ambient Temp
  • One Year Manufacture Warranty.

Aeration Fan Motor. For air over applications or fans mounted directly on the motor shaft. Specifically designed for use on van axial crop dryers and aeration fans. Designed to be used within the airflow of the driven fan

Model C063JCA5265012B; Dayton 4K060

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1-1/2 HP
RPM 3600
Frame 143TZ
Enclosure TEAO
Hertz 60 Hz
Amperage 17.4/8.7 Amps
Insulation Class Class B
!
